Best-in-class network performance, serving low-latency, high-throughput applications up to 2 ports @ 200 Gb/s.
AMD EPYC™ 4th generation
Introducing the AMD EPYC™ 9004 Series Processors family – a powerful and versatile platform designed to deliver exceptional performance, scalability, and security for the most demanding workloads.
With up to 128 high-performance cores and 256 threads, these processors are built to handle the most intensive data center workloads, from enterprise applications to HPC and AI workloads.
The energy efficiency of the EPYC platform also allows you to reduce your carbon footprint and significantly improve your total cost of ownership.
Up to 128 Cores
The world’s highest performance server processors for computing.
Up to 128 PCIe 5.0 Lanes
Go beyond the limits with a number of lanes never seen before.
Up to 400W TDP
The best ratio between number of cores and power consumption.
Up to 4.4GHz in Boost mode
Enjoy even more amazing performance!
Scale with OCP NIC 3.0
Go dense and scale easily thanks to OCP 3.0 Network capabilities.
OCP NIC 3.0 form factor has become OCP’s most impactful project to date.
Ease of scalability
Ease of maintenance
PCIe 5.0 allows you to use your computer at its full potential. Whether to manage more storage or additional graphic, extension card, their 32GT/s transmission speed is more than enough to experience and profit of their power.
788.4x 537 x 45.5mm (latch to hard stop) 31’’x 21’’ x 1.8’’ (latch to hard stop)
2x M.2 NVMe PCIe 5.0 x2 2280/22110
1x 5’’¼ Storage add-on bay : • 5’’¼ Bay for 4 x 2’’½ SATA 6G or SAS 12G from 7 to 15mm height • 5’’¼ Bay for 4 x U.2 NVMe from 7 to 15mm height • 5’’¼ Bay for 6 x 2’’½ SATA 6G or SAS 12G from 7 to 10mm height • 5’’¼ Bay for 8 x 2’’½4 SATA 6G only 7mm height • 5’’¼ Bay for 1 x 3’’½4 SATA 6G with key 4x M.2 NVMe 5.0x2
Single AMD EPYC™ 9004 Series Processor
Single Socket SP5
2x PCIe 5.0 x16 for HH-HL cards 1x PCIe 5.0 x16 OCP v3.0 LAN mezzanine slot
12V DC Busbar connector compliant to OCP ORv1 and ORv2 standard
10°c ~ 35°C
-40°c ~ 70°C
Operative relative humidity
20% ~90% (Non condensing)
2CRSi hardware warranty includes a one year, parts and labour with return to 2CRSi selling entity. Customers may purchase an extended warranty of up to 3 years on parts and labour with different support levels. Please contact 2CRSi at firstname.lastname@example.org or reach your sales point of contact for complete warranty details including limitations and transferability. 2crsi.com/global-location
