Key Features

World's most efficient x86 CPU
Access the highest performance with the AMD EPYC™ 7xx2 and 7xx3 Series processor family.

Solar Impulse certified
OCtoPus server solutions are certfied since October 2021.

3 years warranty
Full warranty included on all systems.

Up to 8 GPUs in a single server
Be ready for AI or GPU virtualization!

Designed for GPU and FPGA support
Featuring a powerful GPU architecture that supports up to four double- slots or eight single-slot GPUs and FPGAs in a single U chassis, including NVIDIA® A100, AMD Instinct™ MI100 and Xilinx Alveo accelerator to manage your highest AI and HPC and High Frequency workload.
The OCtoPus 1.8 has been especially designed to power at its best hybrid cloud environments in financial computing, machine learning, computational storage, and data search and analytics.
AMD EPYC™ 3rd generation
Take advantage of the most advanced technologies with AMD EPYC™!
Improve the performance of your cloud or HPC workloads while enjoying enhanced security with AMD infinity guard.
The energy efficiency of the EPYC™ platform also allows you to reduce your carbon footprint and significantly improve your total cost of ownership.

Up to 64 Cores
The world’s highest performance server processors for computing.
Up to 128 Pcie 4.0 Lanes
Go beyond the limits with a number of lanes never seen before.
Up to 280 W TDP
The best ratio between number of cores and power consumption.
Up to 4,10GHz in Boost mode
Enjoy even more amazing performance!

PCIe 4.0
PCIe 4.0 allows you to use your computer at its full potential. Whether to manage more storage or additional graphic, extension card, their 16GT/s transmission speed is more than enough to experience and profit of their power.
Immersion ready
More density, more reliability but less energy and cost!
Discover our immersion solutions.

System | |
Model (Barebone) |
BRB-OC1-108EE-U001
|
Form Factor | 21'' 2OU |
Dimension | 800 x 537.2 x 86mm 31.49’’ x 21’’ x 3.38’’ |
Storage | |
Internal |
1x SSD 2.5''
|
Motherboard | |
CPU | AMD EPYC™ 7xx2 and 7xx3 Series Processor family |
Socket | Dual Socket SP3 (LGA 4094) |
Chipset | System on chip |
Expansions slots | 2x PCIe Gen4 x16 half-length low-profile slots for add-on cards
|
BMC | Aspeed® AST2500 |
Memory | |
Quantity | 16 DIMM slots |
Capacity per module | Up to 128 GB (with RDIMM modules) Up to 128GB (with LRDIMM modules) Up to 256GB (with 3DS RDIMM / LRDIMM modules) |
Speed | DDR4 3200 MHz |
Channels | 2x8 |
Network | 1x RJ45 for dedicated management (IPMI) 2 x 1Gb/s LAN ports (Intel® I350-AM2 controller) |
Front I/O | |
Ports | 2x USB 3.0 Gen1 (Type-A) 1x VGA 2x RJ45 1x RJ45 dedicated IPMI |
Switch/LED | 1x Power button with LED 1x UID button with LED 1 x Reset button 1 x NMI button 1x LAN Status LED 1x LAN Speed LED |
Management Solution | BMC Remote control based on Aspeed® AST2500 remote management controller (Power Control Configuration, Chassis Identify, Boot Option, iKVM, BMC Account Configuration) |
Bios | TBD |
System Cooling | Immersion cooling |
Power Input | |
Type | Busbar connector compliant to OCP ORv1 and ORv2 standard |
Voltage | 12V DC |
